1.6T TRX PIC for 3.2T NPO(100G/lane)

Features
• 16-lane optical modulator photonic integrated circuit transmitter (TRX PIC) for optical fiber interconnects.
• Converts electrical signals to optical signals on edge coupled outputs, when powered by external laser(s).
• 16 lanes, each capable of independent 1GBaud to 56GBaud PAM4 and NRZ modulation.
• Available with RF pinouts that match popular driver chips.
• Compliant to IEEE Std 802.3df™‐2024 transmitter specification when assembled with suitable drivers, controller, lasers, and optical fibers.
• For use with 4 (or 8) lasers, each powering 8 (or 4) lanes. Contains optical power splitters to direct laser power to TX lanes.
• Singulated bare die or 8-inch diameter wafer.

Applications
• For Ethernet, InfiniBand, and proprietary applications.
• NPO, CPO and On-Board Optics.
• Linear Optical Links.
